Automatic Horizontal Flow Pillow Insole Shoe-Pad Brioche Packing
Machine
Flow Packing Machine With 3 Servo Motors Feature:
Adopt the fibre optical sensor to detect the length of product
automatically, so the product length is not required.
2. Detect the products automatically, if no product go into the
film, the machine will stop, no empty bag and no cutting the
products.
3. Servo motor controls the horizontal sealing device, air cylinder
controls the cutter. Simple operation and convenient maintenance.
4. More quiet working, more stable running, more delicate
construction.
5. Adopt imports electric appliance, touched screen with easy
setting up parameter and fault self-diagnosis function, good
understanding for fault on the screen.
6. High sensitive sensor to track the eye mark, so the position of
sealing and cutting will be more accuracy.
7. Independent PID controls the temperature, so various film
materials can be used.
8. Fixed position and machine stops, no waste the film and no stick
on the cutter.
9. Simple driving system, reliable working, convenient maintenance.
Machine parameters:
| 机型(Model) | ZS-580X |
| 薄膜宽度(Film width) | Max 580mm |
| 制袋长度(Bag length) | 120-1000mm |
| 制袋宽度(Bag width) | 100-250mm |
| 产品高度(Product height) | 5-75mm |
| 膜卷直径(Film roll diameter) | Max 300mm |
| 包装速度(Packaging speed) | 20-120bag/min |
| 包装材料(Packaging materials) | OPP, OPP/PE, OPP/CPP |
| 电源规格(Power) | 220V,50/60Hz,4.25KW |
| 机器尺寸(Machine size) | (L)4210×(W)1070×(H)1400 mm |
| 机器重量(Machine weight) | 650Kg |
Main performance and characteristics:
1.controlled by three servos;
2.touch screen display screen, easy to operate, machine working
state clear;
3.can automatically adjust bag length according to material length
without manual setting;.
4.reduce the labor intensity of operators and improve production
efficiency
5.can store a variety of product parameters and formulations,
without repeated settings, download can be used;
